Welcome to Lami Coat Equipments

We are Manufacturers of Testing Instruments For Inks, Paints, Packaging, Adhesive Tapes, Silicon Coating, Lables, Cosmetics, Toffees, Mango Pulp & Tomato Ketchup Etc.




Hand Bar Coater

BarCode Tester
Bar Coater No. Wet Film Deposit
(In Microns)
U.S No Colour of Handle
0 4 2 White
1 6 3 Yellow
2 12 6 Red
3 24 12 Green
4 36 20 Black
5 50 25 Horn
6 60 30 Orange
7 75 40 Brown
8 100 50 Blue
9 120 - Tan
Figures of Application wt. (Dry Deposition) for guidance purpose only
Ink : Sp. Gr. = 0.9260 % Siolids = 16.00%
Bar Coater No. Dry Deposition in gms/Sq.M.
1 0.76
2 1.24
3 2.92
4 5.16
5 7.76
6 9.24
7 11.12
8 13.08
Products
  • Bond / Heat Seal Strength Tester
  • Tack Rolling Ball
  • Shear Holding Power Tester
  • Automatic Film Applicator
  • Automatic Scratch Hardness Tester
  • Colour Matching Cabinet
  • Flexo Hand Proofer
  • Impression Pad
  • C.O.F Tester (Static)
  • Circular Sample Cutter
  • Peel Adhesion / Silicone Release Tester (1800)
  • Lab Heat Sealer (Pneumatically Operated)
  • Services

    We do provide repairing services of instruments supplied by us at our premises only.
